Bolts Through Bolt for Hydraulic Rock Breaker Hammer

Availability:

Quantity:



Inquire Add to Basket

Model:
all model
Place Of Origin:
China
MOQ:
10PC
Payment Terms:
T/T, L/C, Western Union
Package Details:
standard exporting package
Delivery Time:
3-5days
OEM ODM:
available

Front head, back head and cylinder can be fixed together by through bolt, side bolt and nut. So can be main body and bracket.

The longest service life due to applied heat treatment.

All of our through bolts and side bolts had been done heat treatment, so the quality of complete is more than 12.9 class.

MODEL	Commodity	Specification
Soosan-40	Through Bolt	M27*572
Soosan-43	Through Bolt	M30*605
Soosan-43	Through Bolt	M27*685
Soosan-45	Through Bolt	M338839
Soosan-50	Through Bolt	M398882
Furukawa-20G	Through Bolt	M426968
GB8AT	Through Bolt	M446991
Furrukawa-30G	Through Bolt	M4861050
Soosan81	Through Bolt	M5261050
Soosan121	Through Bolt	M5661150
Soosan100	Through Bolt	M5661210
Furukawa27	Through Bolt	M466986
Toku150	Through Bolt	M466986
Furukawa35	Through Bolt	M5061080

NO.	Item	Model	Specification	Remark
1	Bracket Bolts (set)	SB40	M272230
3		SB43	M272257
4		SB43	M302250
7		SB45	M302280
9		SB50	M363315
10		SB81N	M486445
11		SB81N	M486420
12		SB81	M486445
13		SB81	M486430
14		HB20G	M486445
16		SB121 /SB100	M568510
17		SB100	M488480
18		SB121	M486510
19		SB131 SB151	M568510
20		SB131 SB151	M568570
