Excavator Attachments title Quick Hitch Backhoe Loader

Availability:
Quantity:
Inquire Add to Basket

  • SLK09

  • SLYM

  • China

  • 1PC

  • T/T, L/C, Western Union

  • standard exporting package

  • 3-5days

  • 12month

  • available

  • 23-30ton

  Characteristics of our quick hitch:

  1. Use material of high hardness; Suitable for different excavator of 2-45ton.
  2. Use security device with hydraulic control valve to ensure the safety.

  Our Service:

 1)  Any your inquiry related our products will be replied with 24 hours
 2)  We can also provide OEM business
 3)  Warranty: 1 year and For free techinical support all the time.
 4) How to get the correct information of goods? Pls let us know the following news:


   a. Your excavator model

   b. The operation weigt of your excavator

   c. The quantity of your order

   d. Your destination port


  Suitable excavator:


型号 品牌_meitu_1_conew1

 quick hitch description22031618350

       Item        Unit        SLK09
       Overall length(L)        mm        983-1,050
       Overall Height(H)        mm        574
       Overall Width(W)        mm        543-568
       Pin To Pin Center Distance(A1)        mm        473-540
       Forearm Open Width(W1)        mm        375-411
       Retractable Distance Of Oil Cylinder(A2)        mm        413-590
       Top To Bottom Pin Distance(H1)        mm        300
       Pin Diameter(D)        mm        80-90
       Weight        kg        420-430
       Working Pressure        kg/cm2        40-380
       Required Oil Flow        l/min        10-20
       Suitable Excavator        ton        23-30


Application:

1. Can be used on excavator to change the accessories ( such as bucket, breaker, shear, etc) easily and quickly, which has enlarged the use scope of the excavators and saved a lot of time.

2. Can change the accessories without disassembling the pin and axle, thus realize faster installation

application of quick hitch202203161
