Excavator Slym Hydraulic Digger title Quick Hitch

Availability:

Quantity:



Inquire Add to Basket

Model:
SLK08
Brand:
SLYM
Place Of Origin:
China
MOQ:
1PC
Payment Terms:
T/T, L/C, Western Union
Package Details:
standard exporting package
Delivery Time:
3-5days
Warranty:
12month
OEM ODM:
available
Suitable Excavator:
17-23ton

Characteristics of our quick hitch:

1. Use material of high hardness; Suitable for different excavator of 2-45ton.

2. Use security device with hydraulic control valve to ensure the safety.

Our Service:
1) Any your inquiry related our products will be replied with 24 hours
2) We can also provide OEM business
3) Warranty: 1 year and For free techinical support all the time.
4) How to get the correct information of goods? Pls let us know the following news:

a. Your excavator model
b. The operation weigt of your excavator
c. The quantity of your order
d. Your destination port

Suitable excavator:

.

Item	Unit	SLK08
Overall length(L)	mm	924-944
Overall Height(H)	mm	492
Overall Width(W)	mm	449-483
Pin To Pin Center Distance(A1)	mm	460-480
Forearm Open Width(W1)	mm	306-340
Retractable Distance Of Oil Cylinder(A2)	mm	256-390
Top To Bottom Pin Distance(H1)	mm	275
Pin Diameter(D)	mm	70-80
Weight	kg	280-290
Working Pressure	kg/cm2	40-380
Required Oil Flow	l/min	10-20
Suitable Excavator	ton	17-23

Item	Unit	SLK08
Overall length(L)	mm	924-944
Overall Height(H)	mm	492
Overall Width(W)	mm	449-483
Pin To Pin Center Distance(A1)	mm	460-480
Forearm Open Width(W1)	mm	306-340
Retractable Distance Of Oil Cylinder(A2)	mm	256-390
Top To Bottom Pin Distance(H1)	mm	275
Pin Diameter(D)	mm	70-80
Weight	kg	280-290
Working Pressure	kg/cm2	40-380
Required Oil Flow	l/min	10-20
Suitable Excavator	ton	17-23
