Small Slym Hydraulic Title Quick Hitch Excavator Digger Attachment

Color: Blue, yellow, black, orange...
Min Order: 1 pc
Sales Models: wholesale, retail

Availability:

Quantity:



Inquire Add to Basket

Model:
SLK55
Brand:
SLYM
Place Of Origin:
China
MOQ:
1pc
Payment Terms:
L/C, T/T
Package Details:
standard export packaging
Delivery Time:
3-5days
Warranty:
12 months
OEM ODM:
avalible
Suitable Excavator:
5-8ton

Characteristics of quick hitch:

1. Use material of high hardness; Suitable for different excavator of 2-45ton.

2. Use security device with hydraulic control valve to ensure the safety.

The main structure of excavator hydraulic quick hitch and accessories:

1) Body
2) Cylinder
3) Hitch
4) Hitch Pin
5) Safety Pin
6) R-type Stop Ring
7) Cyliner Pin
8) Snap Ring
9) Frame Pin
10) Bracket Pin
11) Safety Bar
12) Latch Of Safety
13) Hose
14) Check Valve
15) Hook

Our Service:

1) Any your inquiry related our products will be replied with 24 hours

2) We can also provide OEM business

3) Warranty: 1 year and For free techinical support all the time.

4) How to get the correct information of goods? Pls let us know the following news:

a. Your excavator model

b. The operation weigt of your excavator

c. The quantity of your order

d. Your destination port

Suitable Excavator:

Item	Unit	SLK55
Overall length(L)	mm	600
Overall Height(H)	mm	310
Overall Width(W)	mm	270-280
Pin To Pin Center Distance(A1)	mm	290-360
Forearm Open Width(W1)	mm	180-200
Retractable Distance Of Oil Cylinder(A2)	mm	340-450
Top To Bottom Pin Distance(H1)	mm	195
Pin Diameter(D)	mm	50-55
Weight	kg	80
Working Pressure	kg/cm2	40-380
Required Oil Flow	l/min	10-20
Suitable Excavator	ton	5-8

Item	Unit	SLK55
Overall length(L)	mm	600
Overall Height(H)	mm	310
Overall Width(W)	mm	270-280
Pin To Pin Center Distance(A1)	mm	290-360
Forearm Open Width(W1)	mm	180-200
Retractable Distance Of Oil Cylinder(A2)	mm	340-450
Top To Bottom Pin Distance(H1)	mm	195
Pin Diameter(D)	mm	50-55
Weight	kg	80
Working Pressure	kg/cm2	40-380
Required Oil Flow	l/min	10-20
Suitable Excavator	ton	5-8
